Product Details
Key Features
- One-Piece natural finish crankcase
- Non-ringed cylinder construction
- Two Bronze Crankshaft Bushings (sometimes called oilite bearings)
- Schnuerle Porting (Schnuerle scavenging)
- Side Exhaust
- Nylon Backplate with Remote Needle Valve
- #10G carb with remote needle valve assembly
In The Box
- Expansion-Style Muffler #871
- .15LA Engine w/Carb
- Instructions, Decal Sheet, and Warranty Card
- Two 2.6x23mm screws to bolt muffler to engine
- 1.5 inch length of fuel tubing for remote needle valve
- One #A3 glow plug
Needed to Complete
- Glow Fuel with 5-15% Nitromethane and 20% (minimum) lubricant content Glow starter, plug wrench and field equipment
Product Specifications
- Manufacturer #: 11532
- Benchmark Prop: 8×4 break-in
- Bore: 0.598″ (15.2mm)
- Carb Type: Rotary
- Crankshaft Threads: UNF1/4-28 M5
- Crankshaft Type: Threaded
- Cylinders: Single
- Displacement: 0.15 cu in (2.49 cc)
- Engine (Only) Weight: 4.87oz (138g) w/o muffler
- Power Type: Glow
- Muffler Type: 2-piece aluminum
- Muffler Weight: 1.5oz (42g)
- Oil Type & Content: At least 18% synthetic lubricant
- Plug Type: O.S. A3
- Product Height: 2.4″ (61mm) crankcase botton to top of cylinder head
- Product Length: 2.16″ (56.5mm) from back plate to front of drive washer
- Product Width: 1.6″ (40mm) at mounting tabs
- Prop Range: 7×5-6 x 8×4-5
- RPM Range: 2,500 – 18,000
- Stroke: 0.539″ (13.7mm)
