Product Details
Product Specifications
- Manufacturer #: 38160
- Bore: 1.091″ (27.7mm)
- Carb Type: Rotary
- Crankshaft Threads: UNF5/16-24
- Crankshaft Type: Threaded
- Cylinders: Single
- Displacement: 0.912 cu in (14.95 cc)
- Engine (Only) Weight: 22.26 oz (631 g)
- Power Type: Gas
- Ignition Weight: 3.35 oz (95 g)
- Muffler Type: 2-piece aluminum
- Muffler Weight: 6.28 oz (178 g)
- Oil Type & Content: 2-cycle oil at 30:1 – 50:1 mix ratio
- Plug Type: CM6
- Product Height: 4.3″ (109mm) from crankcase bottom to top of cylinder head
- Product Length: 4.2″ (106.2mm) from pump to front bearing
- Product Width: 2.4″ (61mm) at mounting tabs
- Prop Range: 13 x 8-11 – 15×8
- RPM Range: 2,000 – 15,000
- Starter Type: Hand Held Starter
- Stroke: 0.976 (24.8mm)
- Total Weight: 32 oz (904 g)
