Product Details

Product Specifications

• Manufacturer #: 38160
• Bore: 1.091″ (27.7mm)
• Carb Type: Rotary
• Crankshaft Threads: UNF5/16-24
• Crankshaft Type: Threaded
• Cylinders: Single
• Displacement: 0.912 cu in (14.95 cc)
• Engine (Only) Weight: 22.26 oz (631 g)
• Power Type: Gas
• Ignition Weight: 3.35 oz (95 g)
• Muffler Type: 2-piece aluminum
• Muffler Weight: 6.28 oz (178 g)
• Oil Type & Content: 2-cycle oil at 30:1 – 50:1 mix ratio
• Plug Type: CM6
• Product Height: 4.3″ (109mm) from crankcase bottom to top of cylinder head
• Product Length: 4.2″ (106.2mm) from pump to front bearing
• Product Width: 2.4″ (61mm) at mounting tabs
• Prop Range: 13 x 8-11 – 15×8
• RPM Range: 2,000 – 15,000
• Starter Type: Hand Held Starter
• Stroke: 0.976 (24.8mm)
• Total Weight: 32 oz (904 g)
